Center Unit | Bluetooth Version/Profile | Ver. 2.1 + EDR / A2DP AVRCP ; [Audio Codec] SBC AAC |
---|---|---|
Bluetooth Maximum Communication Range | 10 m / 32.8 ft. 10 in. (without interference) | |
Disc Type | CD CD-R CD-RW (Audio CD MP3 WMA) |
|
USB | Yes | |
Internet Radio | vTuner | |
Wi-Fi | Yes | |
AirPlay | Yes | |
DLNA | Yes | |
File Format | MP3 WMA MPEG4 AAC WAV(*1) FLAC(*1) AIFF(*1) ALAC(*2) — (*1) 192 kHz / 24bit; (*2) 96 kHz / 24 bit |
|
Ethernet | Yes | |
Tuner | DAB DAB+ FM |
|
Preset Memory | DAB x 30 FM x 30 |
|
Headphone Jack | Yes | |
Digital Audio Input: Optical | Yes | |
Total Harmonic Distortion(CD to Sp Out 20 Hz-20 kHz) |
0.05 % (SP Out 1 kHz 6 ohms) |
|
Dynamic Range | 100dB | |
Output Power/Channel (6 ohms 1 kHz 10% THD) |
65 W + 65 W | |
[Player] Harmonic Distortion + Noise (1 kHz) | 0.003% | |
[Player] Dimensions (W x H x D) | 314 x 70 x 338 mm; 12-3/8” x 2-3/4” x 13-1/4” | |
[Player] Weight | 2.9 kg; 6.5 lbs. | |
[Receiver] Dimensions (W x H x D) | 314 x 70 x 342 mm; 12-3/8” x 2-3/4” x 13-1/2” | |
[Receiver] Weight | 3.3 kg; 7.3 lbs. | |
Speaker System | Type | 2-way bass-reflex bookshelf |
Woofer | 13 cm (5-1/4”) cone | |
Tweeter | 3 cm (1-1/4”) soft dome | |
Input Power (Max/Nominal) | 110 W / 60W | |
Frequency Response | 55 Hz – 40 kHz | |
Sensitivity | 85 dB / 2.83 V 1 m |
|
Crossover Frequency | 4 kHz | |
Impedance | 6 ohms | |
Dimensions (W x H x D) | 176 x 310 x 297 mm; 6-7/8” x 12-1/4” x 11-3/4” | |
Weight | 4.6 kg; 9.9 lbs. |
